Description
KEY FEATURES
The EL Range with the FieldPro package features a new connection for the new quick adjustment strap, an improved measurement button, new integrated objective covers and redesigned rain-guard.
The rotating strap connector adapts easily to any movement and can be quickly fitted to your EL Range
The quick catch button on the strap easily adjusts to an ideal length within seconds
The objective covers are securely fastened to provide the best protection against external impacts
Easily feel the measurement button, even when wearing gloves
Redesigned rain-guard/ocular cover stays put
Ergonomically designed with rounder edges and more comfortable thumb rests
Lightweight and compact
Unprecedented light transmission – 91% for each barrel
Effective range of 33 to 1500 yards
Scan mode
Red LCD display has optional auto-brightness or fixed brightness
SWARO-AIM Technology – gives corrected ballistic trajectory yardage distance for angled shots at the push of a button
Extremely wide field of view
4 position eyecups for 100% field of view
TECHNICAL INFORMATION
Magnification (mm): 8X
Effective Objective Lens Diameter (mm): 42
Exit pupil distance (mm): 5.3
Exit Interpupillary diameter (mm): 19.2
Field of View (ft/1000 yds): 411
Field of View, real (degrees): 7.8
Field of View for Eyeglass Wearers (degrees): 7.8 = 100%
Field of view, apparent (degrees): 16.4
Shortest Focusing Distance (ft): -7 / +5
Dioptric compensation: (dpt) 18.3
Interpupillary distance (mm): 56 – 74
Light Transmission (%): 91
Twilight factor acc. to DIN 58388:
Measuring Accuracy (yds): ± 1
Measuring Time (sec): ≤ 1
Angular Measurement: ± 90º
Battery: CR2
Undervoltage display: Yes
